Application DataCombustion Ion Chromatography (C-IC)
【New】AQF-5000H Automatic Quick Furnace for Combustion Ion Chromatography
Advanced, developed to the third generation
Powerful fast solution for Sulfur and Halogen analysis
(Fluoride, Chloride, Bromide and Iodide)
USER-FRIENDLY SOFTWARE
Newly designed software with improved user experience.
WIDE CONCENTRATION RANGE ANALYSIS
Newly designed absorption tube for easy switching between applications in a wide range of concentrations. Advanced liquid handling with possiblity for multiple analysis with different dilutions out of one combustion/absorption. Sample collector add on for storage and further analysis.
PLUG-IN OPTION DESIGN
Optional units can be integrated directly into the absorption unit, combining smart appearance, quick upgrade possibility and easier maintenance.
SWITCHING TWO SOLUTIONS FOR ABSORPTION SOLUTION
Automated switching between applications requiring pure water or requiring additives.
EASY, SECURE AND REPEATABLE COMBUSTION
Easily customizable combustion programs that provide reliable combustion with full recovery.
HIGHLY SENSITIVE AND ACCURATE ANALYSIS
Highly sensitive and accurate analysis is enabled by optimizing all components for low instrument blanks and emphasizing repeatability and precision of all process steps from sample introduction through combustion to keeping the final absorption volume truly constant.
EASY MAINTENANCE
Easy accessibility of all relevant parts including combustion tube ensures minimum downtimes, reduces consumable wear and maintains precision over a long period of time.
PARALLEL OPERATION FOR HIGH THROUGHPUT
Parallel operation of sample preparation (combustion) and ion chromatography (quantification) enables fast cycling times and increases sample throughput (or number of replicates).
| Sample introduction | Automated boat control |
|---|---|
| Sample | Solid, Liquid |
| Amount |
1-150mg (solid), 5-100µL (Liquid) |
| Sample pyrolysis | High purity quartz tube (ceramic option) |
| Ekectric furnace |
Max. 1,100℃, Openable electric furnace, 2 heating zones (Temperature individually controlled) |
| Injection to IC | Loop 100µL (5, 20, 50, 200, 500, 1000µL option) |
| Tubing material | Fluoro-resin (low blank), PEEK |
| Signal output | Contact signal to start Ion Chromatograph) |
| Gas |
Argon (purity 99.98% or higher, 0.3±0.1MPa) Oxgen (purity 99.98% or higher, 0.3±0.1MPa) |
| Power supply |
AC100-240VAC, 50/60Hz |
Automatic Sample Changer Model ASC-570LS for Solid and Liquid samples
ASC570LS can automatically measure each measurement target by switching between liquid measurement mode and solid measurement mode.
Automatic Boat Controller Model ABC-500
Manually inject liquid samples and set up boats.
The boat is introduced into the horizontal furnace
according to a set program.
Syringe Pump SP-C for calibration
It can be prepared calibration curve solutions of different concentrations from one calibration curve solution by automatic dilution.
